Direct-Drive Gimbal Architecture
Torque motors drive payload axes directly—eliminating gears, backlash and transmission lag for mission-critical tracking.
· Sub-arcminute precision: ≤0.02° positioning accuracy maintains lock on small, agile targets (e.g. Class 1 UAVs)
· Ultra-wide speed range: Pan 0.09° ~ 120°/s, tilt 0.09° ~ 110°/s—seamless transition from micro-scan to high-speed pursuit
· Instant response:<10 mSec latency counters rapid target manoeuvres and platform vibration
· Unlimited motion: 360° continuous pan, ±90° tilt—no blind zones, no mechanical stops
Multi-Spectral Payload Options
· Thermal: 15 ~ 100mm F1.0 lens, 640×512 uncooled core — penetrates darkness, fog and smoke
· Visible: 1/1.8" 4MP 92× (6.1~561mm) optical zoom camera — Ultra long-range & Ultra-low light
· Illumination: 850nm laser illuminator (500m range) for covert night operations
· Optional modules:
o 1535nm eye-safe laser rangefinder (15–3000m, ±1m accuracy)
o 4MP wide-angle situational awareness camera (4mm F1.0)
o Integrated GPS and digital compass for real-time geolocation
Gyro-Stabilised Platform (Optional)
Dual-axis gyro stabilization compensates for vessel roll, vehicle vibration, and platform motion — delivering shake-free imagery in maritime patrol, off-road, and airborne applications.
Edge AI Capabilities
· AI-adaptive autofocus: maintains sharp imagery across thermal/visible transitions
· AI noise reduction: enhances low-light clarity without detail loss
· AI target recognition & tracking: persistent lock on personnel, vehicles and UAVs despite occlusion or evasive manoeuvres
Operational Deployment
Border and coastal surveillance · Critical infrastructure protection · Naval and vehicle-mounted observation
Engineered for 24/7 operation in extreme environments: dust-proof, salt-spray resistant.
